Tadiran TL-2150/S 3.6V 1/2 AA 1 Ah Lithium Battery (ER14250)

SKU:20158

Tadiran

$7.79
(No reviews yet) Write a Review
SKU:
20158
UPC:
628848201580
Minimum Purchase:
2 units
Bulk Pricing:
Buy in bulk and save
Size:
1/2 AA
Chemistry:
Lithium Thionyl Chloride
Voltage:
3.6 Volt
Terminal:
Button Top
Rechargeable:
No
ecotax_id:
18
ecotax_qty:
1
Adding to cart… The item has been added
Qty. Price
Product Specifications

Specifications

  • Voltage: 3.6 Volt
  • Capacity: 1 Ah
  • Size: 1/2 AA
  • Chemistry: Lithium Thionyl Chloride (Li-SOCI2)
  • Brand: Tadiran
  • Termination Style: Button Top
  • Shelf Life: 10+ Years
  • Maximum Recommended Continuous Current: 50 mA
  • Maximum Pulse Current Capability: 100 mA
  • Diameter(max): 14.5 mm (0.57 in)
  • Height (max): 25.2 mm (0.99 in)
  • Typical weight: 9.2g (0.32 oz)

Features

  • High operating voltage, stable during most of the application lifetime
  • Some of the highest nominal capacities on the market toda
  • Excellent reliability over extended operating life
  • Operating Temperature Range: -60°C/+85°C (-76°F/+185°F)
  • Low self-discharge rate (less than 1% after 1 year of storage at + 20°C)
  • Excellent resistance to humid environments
  • Low magnetic signature
  • Non-flammable (and non-pressurized at ambient temperature) inorganic (but corrosive) electrolyte
  • Less than 1% capacity loss during storage at ambient temperature before use

Compatible With

  • Tadiran TL-4902
  • Tadiran TL-5101
  • Tadiran TL-5902
  • Tadiran TL-5111
  • Saft LS-14250
  • Saft LS-14250c
  • Toshiba ER3v
  • Sonnenschein SL-350/S
  • Sonnenschein SL-750/S
  • Sonnenschein SL-150/S 14250

Warning

  • This battery is not rechargeable. Do not try to recharge.
  • The storage area should be clean, cool (not exceeding +30 Deg C ), dry and ventilated
  • Don't use different models of battery in series
  • Soldering the tab should be finished in few seconds
  • Do not use if the battery casing was mangled

Tadiran TL-2150/S Batteries

The Tadiran TL-2150/S is a 3.6V lithium thionyl chloride battery that offers excellent reliability and high performance for a wide range of applications. This battery comes with a button top termination style and has a capacity of 1Ah, which is one of the highest nominal capacities on the market today for this size of battery.


The TL-2150/S is a 1/2 AA size battery, with a diameter of 14.5mm (0.57 in) and a height of 25.2mm (0.99 in). It weighs 9.2g (0.32 oz), making it lightweight and easy to carry around.


One of the key advantages of the TL-2150/S is its high operating voltage, which remains stable during most of the application lifetime. This makes it an excellent choice for devices that require a consistent and reliable power source. Additionally, it has an operating temperature range of -60°C to +85°C (-76°F to +185°F), which means it can function in a wide range of environments and conditions.


The TL-2150/S also has a low self-discharge rate, which means it can retain its charge for a long time even when not in use. It has a shelf life of 10+ years and less than 1% capacity loss during storage at ambient temperature before use. This makes it an ideal choice for devices that are not frequently used, such as remote controls, alarms, and other similar applications.


In terms of performance, the TL-2150/S has a maximum recommended continuous current of 50 mA and a maximum pulse current capability of 100 mA. This means it can deliver bursts of power when needed, making it suitable for devices that require intermittent high-power output.


The TL-2150/S is also highly durable, with excellent resistance to humid environments and a low magnetic signature that makes it suitable for use in sensitive electronic devices. Its inorganic (but corrosive) electrolyte makes it non-flammable (and non-pressurized at ambient temperature), adding to its safety and reliability.


In addition to the TL-2150/S, Tadiran offers a range of other high-quality lithium thionyl chloride batteries, including the TL-4902, TL-5101, TL-5902, and TL-5111. Saft also offers comparable batteries, such as the LS-14250 and LS-14250c.


Overall, the Tadiran TL-2150/S is an excellent choice for anyone looking for a reliable and high-performance battery. Its high operating voltage, stable performance, and low self-discharge rate make it an ideal choice for a wide range of applications, from remote controls to industrial sensors and beyond.
