Battery Charts
| Cell Size | Voltage | Size (mm) | Replaces |
| CR927 | 3 | 9.5 X 2.7 | DL927, ECR927, BR927, GR927, DL927B, BR927-1W, CR927-1W, KCR927, LM927, CX927, CX 927 |
| CR1025 | 3 | 10 X 2.5 | BR1025, CR1025, DL1025, ECR1025, KCR1025, L1025, LM1025, 5033LC |
| CR1216 | 3 | 12.5 X 1.6 | DL1216, ECR1216, BR1216, DL1216B, BR1216-1W, CR1216-1W, KCR1216, LM1216, 280-208, 5034LC |
| CR1220 | 3 | 12.5 X 2 | DL1220, DL1220B, BR1220, BR1220-1W, ECR1220, CR1220-1W, KCR1220, LM1220, SB-T13, L04 |
| CR1225 | 3 | 12.5 x 2.5 | BR1225, DL1225, DL1225B, BR1225-1W, CR1225-1W, KCR1225, ECR1225, E-CR1225, LM1225, 5020LC, L30 |
| CR1612 | 3 | 16 x 1.2 | BR1612, BR1612-1W, CR1612-1W, DL1612, DL1612B, KCR1612, LM1612 |
| CR1616 | 3 | 16 x 1.6 | CR1616, DL1616, DL1616B, BR1616, BR1616-1W, E-CR1616, CR1616-1W, KCR1616, LM1616, 208-202, 5021LC, L11, L28, YA |
| CR1620 | 3 | 16 x 2 | DL1620, DL1620B, BR1620, BR1620-1W, ECR1620, CR1620-1W, KCR1620, LM1620, 5009LC, L08 |
| CR1625 | 3 | 16 x 2.5 | DL1625, ECR1625, BR1625, DL1625B, BR1625-1W, CR1625-1W, KCR1625, LM1625 |
| CR1632 | 3 | 16 x 3.2 | DL1632, BR1632, KL1632, L1632, ECR1632, KCR1632, E-CR1632, KECR1632 |
| CR2012 | 3 | 20 x 1.2 | BR2012, BR2012-1W, CR2012-1W, DL2012, DL2012B, ECR2012, KCR2012, LM2012, SBT15, SB-T15, 280-207 |
| CR2016 | 3 | 20 x 1.6 | CR2016, DL2016, ECR2016, BR2016, DL2016B, BR2016-1W, CR2016-1W, LM2016, SBT11, L10, LF1/4V, 208-202, 208-204, 208-206 |
| CR2025 | 3 | 20 x 2.5 | DL2025, ECR2025, BR2025, LM2025, DL20256B, BR2025-1W, CR2025-1W, KCR2025, L12, SB-T14, LF1/2V, 5003LC, 208-205 |
| CR2032 | 3 | 20 x 3.2 | CR2032, BR2032, KL2032, L2032, KCR2032, E-CR2032, ECR2032, KECR2032, 5004LC, SB-T1 |
| CR2320 | 3 | 23 x 2 | CR2320, DL2320, BR2320, KL2320, L2320, ECR2320, E-CR2320, KCR2320, KECR2320, L26 |
| CR2325 | 3 | 23 x 2.5 | DL2325, CR2325, KL2325, L2325, ECR2325, KCR2325, E-CR2325, KECR2325 |
| CR2330 | 3 | 23 x 3 | DL2330, BR2330, KL2330, L2330, ECR2330, KCR2330, E-CR2330, KECR2330 |
| CR2335 | 3 | 23 x 3.5 | DL2335, BR2335, ECR2335, KL2335 |
| CR2354 | 3 | 23 x 5.4 | DL2354, BR2354, KL2354, L2354, ECR2354, KCR2354, E-CR2354, KECR2354 |
| CR2412 | 3 | 24.5 x 1.2 | CR2412, BR2412, DL2412, ECR2412, E-CR2412, KCR2412, KECR2412, KL2412, L2412, COMP-274-PANA |
| CR2430 | 3 | 24.5 x 3 | DL2430, BR2430, KL2430, L2430, E-CR2430, ECR2430, KCR2430, KECR2430, L20, 5011LC, LF1/2W |
| CR2450 | 3 | 24.5 x 5 | CR2450, ECR2450, KCR2450, BR2450, BR2450-1W, LM2450, 5029LC |
| CR2477 | 3 | 24.5 x 7.7 | DL2477, CR2477, ECR2477, BR2477, BR2477-1W, CR2477, KCR2477, LM2477 |
| CR3032 | 3 | 30 x 3.2 | DL3032, BR3032, KL3032, L3032, ECR3032, KCR3032, E-CR3032, KECR3032 |
| Cell Size | Voltage | Size (mm) | Replaces |
| 23A | 1.5 | 27.94 x 10.31 | MN21, MN23, A23, 1811A, LRV08, V23GA, GP23A, K23A, MB21, MS21, S21, V23, E23A, L1028, PX32A, TR164, E164, 1404M |
| 28L / A544 | 6 | 25.2 x 13 | 1406LC, 1414A, 28, 28A, 28L, 2CR1/3N, 2CR11108, 478A, 4LR44, 544, A544, K28A, K28L, L544, PX28A, PX28L, V28PXL, V34PX, 4SR44 |
| 2CR5 | 6 | 45 x 34 x 17 | 2CR5, 2CR5E, 5032LC, DL245, EL2CR5, RL2CR5 |
| A27 | 12 | 27.94 x 8 | 27A, 8LR732, A27, GP27A, L828, MN27 |
| AAAA | 1.5 | 42 x 8 | LR61, AM6, 25A , MN2500, MX2500, E96, EN96, GP25A, LR8D425, 4061, K4A, Quadruple A, Quad A, 4AAAA |
| CR1/3N | 3 | 11 x 11.6 | 1/3 N, 2L76, 2LR76, 5008L, 5008LC, 72L76, 867, CR1/3N, CR11108, DL1/3N, KL-13N |
| CR123 | 3 | 34.5 x 17 | CR123A, EL123A, EL123AP, DL123A, K123A, VL123A, RL123A, SF123A, 5018LC, CR17345, LC5018 |
| CR2 | 3 | 27.5 x 16 | DLCR2, DLCR2B, RLCR2, KCR2, EL1CR2, RLCR2-L, 5046LC |
| CRP2 | 6 | 35 x 19.5 x 1.41 | 223, 223A, 5024LC, BR-P2, CR-P2, CR17-33, CRP2 |
| N | 1.5 | 50 x 14 | LR1, LR01, 910A , MN9100, 4001, E90, KN, 810, 23-023, AM5, UM5, UM-5, SUM5, Lady Battery |
| Cell Size | Voltage | Size (mm) | Replaces |
| 10 | 1.45 | 5.8 x 3.6 | A10, 10A, 10AE, R10ZA, ME10Z, V10AT, AC10, 20PA, PR-10PA, DA230, AC230, 7005ZD, PR-230PA, 230HPX, PR536, AC230E, PR536, DA230, ZA10, DA10H, 10HPX, L10ZA, ZA10, VT10, PR70, XL10, AP10, B20 |
| 13 | 1.45 | 7.9 x 5.4 | 13A, A13, 13AE, DA13, 13HPX, AC13, P13, PR13H, ZA13, PR48, B0134, B26PA, DA13H, DA13N, 13HP, AC13E, AC13EZ, ME8Z, L13ZA, W13ZA, S13A, 13SA, B26 |
| 312 | 1.45 | 7.9 x 3.6 | A312, 312A, 312AE, DA312, 312HPX, AC312, P312, PR312H, ZA312, PR41, B3124, B347PA, DA312H, DA312N, 312HP, AC312E, AC312EZ, ME7Z, L312ZA, W312ZA, S312A, 312SA, B347 |
| 675 | 1.45 | 5.4 x 11.6 | A675, 675AE, DA675, 675HPX, AC675, P675, PR675H, ZA675, 675HP, DA675N, DA675H, AC675E, AC675EZ, W675ZA, S675A, 675SA, B6754, B900PA,PR44,ME9Z,L975ZA, B900 |
| Alkaline | Silver Oxide | Size (mm) |
| AG0, LR521, LR63 | 379, SR521, SR521SW, SR63 | 5.8 x 2.1 |
| AG1, 164, LR621, LR60, LR620 | 363, 364, SR60, SR621, SR621SW | 6.8 x 2.1 |
| AG2, 196, LR726, LR59 | 396, 397, SR726, SR726W, SR59 | 7.9 x 2.6 |
| AG3, 192, LR41 | 384, 392, SR41W, SR41SW, SR41, SR736 | 7.9 x 3.6 |
| AG4, 177, LR626, LR66 | 376, 377, SR626SW, SR626, SR66 | 6.8 x 2.65 |
| AG5, 193, LR48, LR754, LR750 | 309, 393, SR754W, SR754 | 7.9 x 5.4 |
| AG6, 171, LR920, LR920W, LR921 | 370, 371, SR920SW, SR920W, SR69 | 9.5 x 2.1 |
| AG7, 195, LR926, LR927 | 395, 399, SR927, SR927W, SR927SW, SR57 | 9.5 x 2.6 |
| AG8, 191, LR1120, LR55 | 381, 391, SR55, SR1120, SR1120W | 11.6 x 2.1 |
| AG9, 136, LR936 | 380, 394, SR936, SR936SW | 9.5 x 3.6 |
| AG10, 189, LR1130, LR54 | 389, 390, SR54, SR1130W, SR1130 | 11.6 x 3.1 |
| AG11, 162, LR921, LR721 | 362, SR58, SR721, SR721SW, SR721W | 7.9 x 2.1 |
| AG12, 186, LR43, LR1142 | 301, 386, SR43, SR43W, SR43SW, SR1142 | 11.6 x 4.2 |
| AG13, A76, LR44, PX76A, L1154, LR1154 | 303, 350, 357, SR44, SR44W, SR44SW, SR1154, SR1136W | 11.6 x 5.4 |
| 115, LR716 | 315, SR716SW, 307, SR516W | 7.9 x 1.6 |
| 117, LR516 | 317, SR516SW, 307, SR516W | 5.8 x 1.6 |
| 119, LR527 | 319, SR527SW | 5.8 x 2.6 |
| 121, LR616 | 321, SR616SW | 6.8 x 1.6 |
| 129, LR731 | 329, SR731SW | 7.9 x 3.1 |
| 135, LR512 | 335, SR512SW | 5.8 x 1.2 |
| 137, LR416 | 337, SR416SW | 4.8 x 1.65 |
| 139, LR614 | 339, SR614SW | 6.8 x 1.4 |
| 141, LR714 | 341, SR714SW | 7.9 x 1.4 |
| 144, LR1136 | 344, SR1136SW | 11.6 x 3.6 |
| 146, LR712 | 346, SR712SW | 7.9 x 1.2 |
| 148, LR421 | 348, SR421SW | 4.8 x 2.15 |
| 166, LR1116 | 366, SR1116SW, 365, SR1116W | 11.6 x 1.6 |
| 173, LR916 | 373, SR916SW, 372, SR916W | 9.5 x 1.6 |
| 179, LR521 | 379, SR521SW | 5.8 x 2.1 |
| Cell Size | Chemistry | Voltage | Size (inches) |
| 10440 | Li-Ion | 3.7 | 1.69" x 0.39" |
| 14430 | LiFePO4, Li-Ion | 3.2, 3.7 | 1.72" x 0.55" |
| 14500 | Li-Ion, LiFeP04 | 3.7 | 2.07" x 0.55" |
| 17500 | Li-Ion | 3.7 | 1.97" x 0.67" |
| 18500 | LiFePO4, Li-Ion | 3.2, 3.7 | 1.97" x 0.71" |
| 18650 | LiFePO4, Li-Ion | 3.2, 3.7 | 2.56" x 0.71" |
| 20700 | Li-Ion | 3.7 | 2.77" x 0.8" |
| 22650 | LiFePO4 | 3.2 | 2.56" x 0.87" |
| 26650 | LiFePO4 | 3.2 | 2.56" x 1.02" |
| 32650 | LiFePO4 | 3.2 | 2.66" x 1.26" |
| 1/2 C | NiCd | 1.2 | 0.9" x 0.99" |
| 1/2 D | NiCd, NiMH | 1.2 | 1.37" x 1.27" |
| 1/2 Sub C | NiCd | 1.2 | 1.063" x 0.866" |
| 1/3 AA | NiMH | 1.2 | 0.63" x 0.53" |
| 1/3 AAA | NiMH | 1.2 | 0.71" x 0.39" |
| 2/3 A | NiCd, NiMH | 1.2 | 1.1" x 0.65" |
| 2/3 AA | NiCd, NiMH | 1.2 | 1.1" x 0.55" |
| 2/3 AAA | NiCd, NiMH | 1.2 | 1.1" x 0.40" |
| 4/3 A | NiMH | 3.7 | 1.98" x 0.72" |
| 4/3 A (F) | NiMH | 1.2 | 2.6" x 0.72" |
| 4/5 A | NiCd, NiMH | 1.2 | 1.68" x 0.66" |
| 4/5 AA | NiMH, NiCd, LiFePO4 | 1.2 | 1.69" x 0.55" |
| 4/5 Sub C | NiCd, NiMH | 1.2 | 1.3" x 0.866" |
| A | NiCd, NiMH | 1.2 | 1.97" x 0.67" |
| AA | NiCd, NiMH | 1.2 | 1.9" x 0.55" |
| AAA | NiCd, NiMH | 1.2 | 1.75" x 0.41" |
| C | NiCd, NiMH | 1.2 | 1.81" x 1.2" |
| D | NiCd, NiMH | 1.2 | 2.28" x 1.29" |
| Sub C | NiCd, NiMH | 1.2 | 1.69" x 0.87" |
