The 5-Pack Panasonic BR-1632A/FAN 3V Lithium Batteries with Tabs provides reliable long-term power for electronic equipment requiring a compact PCB-mounted lithium power source. Each battery features Panasonic lithium poly-carbonmonofluoride chemistry, a nominal 3-volt output, and a 120mAh capacity for stable performance in demanding electronic applications.
Panasonic BR-1632A/FAN batteries are specifically designed for high-temperature applications, with an operating temperature range of -40°C to +125°C. The attached Type-F PCB tabs allow the battery to be mounted directly onto compatible circuit boards. Typical applications include automotive electronics, TPMS systems, electricity and hot-water meters, industrial equipment, memory backup systems, and other electronic devices designed specifically for the BR-1632A/FAN battery configuration.
| Brand: | Panasonic |
| Model: | BR-1632A/FAN |
| Product Series: | BR1632A |
| Battery Size: | 1632 Coin Cell |
| Chemistry: | Lithium Poly-Carbonmonofluoride |
| Nominal Voltage: | 3 Volt |
| Nominal Capacity: | 120 mAh |
| Nominal Energy: | Approximately 0.36 Wh |
| Continuous Drain: | 0.03 mA |
| Diameter: | 16.0 mm Maximum (Without Tabs) |
| Height: | 3.2 mm Maximum (Without Tabs) |
| Typical Weight: | Approximately 1.5 g (Without Tabs) |
| Termination Style: | Type-F PCB Tabs / SMD (SMT) Tabs |
| Operating Temperature: | -40°C to +125°C (-40°F to +257°F) |
| Rechargeable: | No |
| Battery Quantity: | 5 Batteries |
Key Features:
- Includes five Panasonic BR-1632A/FAN 3V lithium batteries with tabs
- 120mAh nominal capacity with a stable 3-volt output
- Lithium poly-carbonmonofluoride chemistry for dependable long-term performance
- Designed for high-temperature electronic applications
- Wide operating temperature range from -40°C to +125°C
- Type-F PCB tabs for mounting directly to compatible circuit boards
- Low self-discharge characteristics for excellent storage stability
- Stable operating voltage throughout service life
- Compact 16.0mm × 3.2mm coin-cell format before tabs
- Suitable for automotive, industrial, metering, and memory-backup applications
- Non-rechargeable primary lithium batteries
Common Applications:
- Automotive Electronic Components
- Tire Pressure Monitoring Systems (TPMS)
- Electricity Meters
- Hot Water Meters
- Memory Backup Systems
- Industrial Automation Equipment
- Host Computers & Electronic Control Systems
- Wireless Electronic Equipment
- PCB-Mounted Electronic Devices
- Equipment Designed for BR-1632A/FAN Batteries
Also Known As / Replaces:
- BR-1632A/FAN
- BR1632A/FAN
- BR1632AFAN
- BR-1632A/FA
- BR1632A-FA
- BR1632A/FA
- BR1632A/FAE
- P022
Package Includes:
- 5 × Panasonic BR-1632A/FAN 3V 120mAh Lithium Batteries with Type-F PCB Tabs
